Product Details
High power restricted version must be purchased by and delivered to a law enforcement agency, military base, or other U.S. Government agency ONLY. Sales to individuals are not allowed. For civilian use, we recommend the L3Harris ATPIAL-C Class 1/3R IR Laser.
Co-aligned visible and infrared lasers.
Hardened for use on small arms and crew-served weapons.
Integral Rail-Grabber interface.
Retains zero within 0.5 mrad.
Meets military environmental specifications.
Specifications
Dimensions | 4.6 in. L x 2.8 in. W x 1.6 in. H |
Weight | 7.5 oz. with battery |
Battery Type | (1) 3 Volt Lithium |
Battery Life | > 6 hrs. in Dual High at 25 °C (77 °F) |
Visible Aim Laser | Specifications at 25 °C (77 °F) |
Output Power | 5.0 mW (max) / 3B Safety Class |
Beam Divergence | 0.5 (± 0.3/- 0.39) mrad |
Wavelength | 635 (± 15) nm |
IR Aim Laser | Specifications at 25 °C (77 °F) |
Output Power Low | 700 uW / 3R Safety Class |
Output Power High | 27.5 mW (max) / 3B Safety Class |
Beam Divergence | 0.5 (± 0.3/- 0.39) mrad |
Wavelength | 835 (± 15) nm |
IR Illuminator | Specifications at 25 °C (77 °F) |
Output Power Low | 3.5 mW (max) / 3B Safety Class |
Output Power High | 45 mW (max) / 3B Safety Class |
Beam Divergence | Adjustable from approximately 1 mrad to > 105 mrad |
Wavelength | 835 (± 15) nm |
